| IMAGE SENSOR |
| Type |
36 x 24 mm CMOS |
| Effective Pixels |
Approx. 22.3 megapixels |
| Total Pixels |
Approx. 23.4 megapixels |
| Aspect Ratio |
3:2 |
| Low-Pass Filter |
Built-in/Fixed with fluorine coating |
| Sensor Cleaning |
EOS integrated cleaning system |
| Colour Filter Type |
Primary Colour |
|
| IMAGE PROCESSOR |
| Type |
DIGIC 5+ |
|
| LENS |
| Lens Mount |
EF (excludes EF-S lenses) |
| Focal Length |
Equivalent to 1.0x the focal length of the lens |
|
| FOCUSING |
| Type |
TTL-CT-SIR with a dedicated CMOS sensor |
| AF System/ Points |
61 Point / 41 f/4 cross-type AF points inc 5 dual cross type at f/2.8
The number of cross-type AF points will differ depending on the lens. |
| AF Working Range |
EV -2 – 18 (at 23°C & ISO100) |
| AF Modes |
AI Focus
One Shot
AI Servo |
| AF Point Selection |
Automatic selection: 61 point AF
Manual selection: Single point AF (61, 41 cross type only, 15 or 9 points selectable)
Manual selection: Spot AF
Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding 8 points
Manual selection: Zone AF
AF points can be selected separately for vertical and horizontal shooting |
| Selected AF Point Display |
Superimposed in viewfinder and indicated on top LCD panel and Quick Control screen |
| AF Lock |
Locked when shutter button is pressed half way in One Shot AF mode or AF-ON button is pressed. |
| AF Assist Beam |
Emitted by optional dedicated Speedlite |
| Manual Focus |
Selected on lens, default in Live View Mode |
| AF Microadjustment |
AF Menu
+/- 20 steps ( wide and tele setting for Zooms)
Adjust all lenses by same amount
Adjust up to 40 lenses individually
Adjustments remembered for lens by serial number |
|
| EXPOSURE CONTROL |
| Metering Modes |
TTL full aperture metering with 63 zone Dual Layer SPC
(1) Evaluative metering (linked to All AF point)
(2) Partial metering (approx. 6.2% of viewfinder at centre)
(3) Spot metering (approx. 1.5% viewfinder at centre)
(4) Centre weighted average metering |
| Metering Range |
EV 1 – 20 (at 23°C with 50mm f/1.4 lens ISO100) |
| AE Lock |
Auto: In 1-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in creative zone modes. |
| Exposure Compensation |
+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB). |
| AEB |
2, 3, 5 or 7 Shots +/-3 EV 1/3 or 1/2 stop increments |
| ISO Sensitivity* |
Auto (100-12800), 100-25600 (in 1/3-stop or whole stop increments)
ISO can be expanded to L: 50, H1: 51200, H2 102400 |
|
| SHUTTER |
| Type |
Electronically-controlled focal-plane shutter |
| Speed |
30-1/8000 sec (1/2 or 1/3 stop increments) + Bulb (Shutter speed range available varies according to shooting mode) |
|
| WHITE BALANCE |
| Type |
Auto white balance with the imaging sensor |
| Settings |
AWB, Daylight, Shade, Cloudy, Tungsten, White
Fluorescent light, Flash, Custom, Colour Temperature Setting.
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9. |
| Custom White Balance |
Yes, 1 setting can be registered |
| WB Bracketing |
+/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/ Green bias. |
|
| VIEWFINDER |
| Type |
Pentaprism |
| Coverage (Vertical/Horizontal) |
Approx. 100% |
| Magnification |
Approx. 0.71x¹ |
| Eyepoint |
Approx. 21mm (from eyepiece lens centre) |
| Dioptre Correction |
-3 to +1 m-1 (dioptre) |
| Focusing Screen |
Fixed (Transmissive LCD screen) |
| Mirror |
Quick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF600mm f/4 or shorter) |
| Viewfinder Information |
AF information: AF point, focus confirmation, AF status indicator
Exposure information: Shutter speed, aperture, ISO speed (always displayed), AE lock,
exposure level, exposure warning
Flash information: Flash ready, flash exposure compensation, high-speed sync, FE lock,
red-eye reduction light
Image information: Highlight tone priority (D+), maximum burst (2-digit display), card
information, Battery check
Composition information
Grid, electronic level, Warning symbol
Displayed if any of the following is set: Monochrome, white balance
correction, One-touch recording quality switch, expanded ISO speed, or spot metering |
| Depth of Field Preview |
Yes, with Depth of Field preview button. |
| Eyepiece Shutter |
On strap |
|
| LCD MONITOR |
| Type |
8.11cm (3.2″) Clear View II TFT, approx. 1040K dots |
| Coverage |
Approx. 100% |
| Viewing Angle (Horizontally/Vertically) |
Approx. 170° |
| Coating |
Anti-reflection and Solid Structure |
| Brightness Adjustment |
Adjustable to one of seven levels |
| Display Options |
(1) Quick Control Screen
(2) Camera settings
(3) Dual Axis Electronic Level |
|
| FLASH |
| Modes |
E-TTL II Auto Flash, Metered Manual |
| X-Sync |
1/200sec (EX series Speedlites only) |
| Flash Exposure Compensation |
+/- 3EV in 1/2 or 1/3 increments |
| Flash Exposure Bracketing |
Yes, with compatible External Flash |
| Flash Exposure Lock |
Yes |
| Second Curtain Synchronisation |
Yes |
| HotShoe/ PC Terminal |
Yes/ Yes |
| External Flash Compatibility |
E-TTL II with EX series Speedlites, wireless multi-flash support |
| External Flash Control |
Via camera menu screen |
|
| SHOOTING |
| Modes |
Auto+, Program AE, Shutter priority AE, Aperture priority AE, Manual (Stills and Movie), Custom (x3) |
| Picture Styles |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3) |
| Colour Space |
sRGB and Adobe RGB |
| Image Processing |
Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Auto Correction of Lens Peripheral illumination
Chromatic aberration correction
Distortion correction
Resize to M1, M2 or S
RAW image processing – during image Playback only
Multiple exposure
HDR images 5 presets |
| Drive Modes |
Single, Continuous L, Continuous H, Self-timer (2s+remote, 10s+remote),
Silent single shooting, Silent continuous shooting |
| Continuous Shooting |
Max. Approx. 6fps. (speed maintained for up to 16270 images (JPEG)¹² or 18 images (RAW)) (with UDMA card)² |
|
| LIVE VIEW MODE |
| Type |
Electronic viewfinder with image sensor |
| Coverage |
Approx. 100% (horizontally and vertically) |
| Frame Rate |
30 fps |
| Focusing |
Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Quick mode, Live mode, Live Face detection mode |
| Metering |
Real-time evaluative metering with image sensor
Active metering time can be changed |
| Display Options |
Grid overlay (x3), Histogram, Aspect ratios, Dual Axis Electronic Level |
|
| FILE TYPE |
| Still Image Type |
JPEG: Fine, Normal (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system (2.0),
RAW: RAW, sRAW1, sRAW2 (14bit, Canon original RAW 2nd edition),
Digital Print Order Format [DPOF] Version 1.1 compliant |
| RAW+JPEG Simultaneous Recording |
Yes, any combination of RAW + JPEG possible, separate formats to separate cards possible |
| Image Size |
JPEG: (L) 5760 x 3840, (M) 3840 x 2560, (S1) 2880 x 1920, (S2) 1920 x 1280, (S 3)720 x 480
RAW : (RAW) 5760 x 3840 (M-RAW) 3960 x 2640, (S-RAW) 2880 x 1920 |
| Movie Type |
MOV (Video: H.264 Intra frame / inter frame, Sound: Linear PCM) |
| Movie Size |
1920 x 1080 (29.97, 25, 23.976 fps) intra or inter frame
1280 x 720 (59.94, 50 fps) intra or inter frame
640 x 480 (59.94, 50 fps) inter frame |
| Movie Length |
Max duration 29min 59sec, Max single file size 4GB |
| Folders |
New folders can be manually created and selected |
| File Numbering |
(1) Consecutive numbering
(2) Auto reset
(3) Manual reset |
|
| OTHER FEATURES |
| Custom Functions |
13 Custom Functions with 47 settings |
| Metadata Tag |
User copyright information (can be set in camera)
Image rating (0-5 stars) |
| LCD Panel / Illumination |
Yes / Yes |
| Water/ Dust Resistance |
Yes (equal to EOS-1N)¹ |
| Sound Memo |
No |
| Intelligent Orientation Sensor |
Yes |
| Playback Zoom |
1.5x – 10x |
| Display Formats |
(1) Single image with information (2 levels)
(2) Single image
(3) 4 image index
(4) 9 image index
(5) Magnified view
(6) 2 image compare display
(7) Movie edit |
| Slide Show |
Image selection: All images, by Date, by Folder, Movies, Stills, Rating
Playback time: 1/2/3/5/10 or 20 seconds
Repeat: On/Off |
| Histogram |
Brightness: Yes
RGB: Yes |
| Highlight Alert |
Yes |
| Image Erase/Protection |
Erase: Single image, All images in folder, Checkmarked images, unprotected images
Protection: Erase protection of one image at a time |
| Menu Categories |
(1) Shooting menu (x4)
(2) AF Menu (x5)
(3) Playback menu (x3)
(4) Setup menu (x4)
(5) Custom Functions menu (x4)
(6) My Menu |
| Menu Languages |
25 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese |
| Firmware Update |
Update possible by the user. |
|
| INTERFACE |
| Computer |
Hi-Speed USB |
| Other |
HDMI mini output, Video output (PAL/ NTSC), Headphone mini jack, External microphone (Stereo mini jack) |
|
| DIRECT PRINT |
| Canon Printers |
Canon Compact Photo Printers and PIXMA Printers supporting PictBridge |
| PictBridge |
Yes |
|
| STORAGE |
| Type |
CompactFlash Type I (UDMA compatible), SD card, SDHC card or SDXC card |
|
| SUPPORTED OPERATING SYSTEM |
| PC & Macintosh |
Windows XP (SP2/SP3) / Vista inc SP1 (excl. Starter Edition) / 7 (excl. Starter Edition)
OS X v10.6-10.7 |
|
| SOFTWARE |
| Browsing & Printing |
ImageBrowser EX |
| Image Processing |
Digital Photo Professional |
| Other |
PhotoStitch, EOS Utility (inc. Remote Capture, WFT utility*), Picture Style Editor
* Requires optional accessory |
|
| POWER SOURCE |
| Batteries |
Rechargeable Li-ion Battery LP-E6 (supplied), 1xCR1616 for date & settings |
| Battery Life |
Approx. 950 (at 23°C, AE 50%, FE 50%)¹
Approx. 850 (at 0°C, AE 50%, FE 50%) |
| Battery Indicator |
6 levels + percentage |
| Power Saving |
Power turns off after 1, 2, 4, 8, 15 or 30mins. |
| Power Supply & Battery Chargers |
AC Adapter Kit ACK-E6, Battery charger LC-E6, Car Battery charger CBC-E6 |
|
| PHYSICAL SPECIFICATIONS |
| Body Materials |
Magnesium Alloy body covers |
| Operating Environment |
0 – 40 °C, 85% or less humidity |
| Dimensions (WxHxD) |
152 x 116.4 x 76.4mm |
| Weight (Body Only) |
Approx. 950 |
|
| ACCESSORIES |
| Viewfinder |
Eyecup Eg, Eg-series Dioptric Adjustment Lens with Rubber Frame Eg, Anti Fog Eyepiece Eg, Angle Finder C |
| Wireless File Transmitter |
Wireless File Transmitter WFT-E7 |
| Lenses |
All EF lenses (excludes EF-S lenses) |
| Flash |
Canon Speedlites (220EX, 270EX, 270EX II, 320EX, 420EX, 430EX, 430EX II, 550EX, 580EX, 580EX II, 600EX, 600EX-RT, Macro-Ring-Lite, MR-14EX, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT) |
| Remote Controller/ Switch |
Remote control with N3 type contact, Wireless Controller LC-5, Remote Controller RC-6 |
| Other |
Hand Strap E2, GP-E2 |
|
